| Frame | | Frame shape | Diamant | Wave | | Frame height | 45 cm | 50 cm | 55 cm | 60 cm | | Frame | Alu 6061 | | Fork | SUNTOUR "SF18-MOBIE25 LOR Coil", einstellbar, Lockout, 75mm,Disc, Tapered, QR15 | | Crankset | SHIMANO "FC-E6100", 175mm, schwarz | | Colours | deep black matt / anthracite | | Weight | from 25,0 kg | | Frame | Alu 6061 |
|
|---|
| MOTEUR | | MOTEUR | SHIMANO E7000, 250 W | | Position | moteur central | | Batterie | SHIMANO Lithium-Ion, 36 V, 14 Ah, 504 Wh | | Energy content | 504 |
|
|---|
| Antrieb | | Display | SHIMANO "SC-E61" LCD, Bluetooth, Remote Control, Walk assist | | Sensor | Tretkraftmessung im Motor + Geschwindigkeitssensor |
|
|---|
| Cockpit | | Handlebars | ERGOTEC "Low Riser Bar", 720 mm, Ø 31,8 mm, schwarz | | Stem | ERGOTEC "Barracuda", Ø31,8 mm, 20 °, schwarz | | Handlebar grips | HERRMANS "LineTec" | | Saddle | SELLE ROYAL "ESSENZA" Italy, Moderate Male | | Seat Post | ERGOTEC Patent "SP10", gefedert, Ø 27,2 mm, Alu |
|
|---|
| Brake | | Brake | SHIMANO "BR-MT500", 180/160 mm | | Brake lever | SHIMANO "BL-MT501" |
|
|---|
| Wheels | | Front-wheel hub | SHIMANO "HB-M6010B", 32 L., QR 15, Disc, Center Lock | | Rear-wheel hub | SHIMANO "Deore FH-M6000", 32L., Disc, Center-Lock | | Wheel rims | Hohlkammer "X6" Disc, Alu | | Spokes | 2,0 mm, Niro, schwarz | | Tyres | SCHWALBE "Smart Sam Plus", 57-584, Reflex | | Tire size | 27,5" |
|
|---|
| Shifting system | | Shifting system | Kettenschaltung | | Gears | 10-Gang | | Shifting | 1_10-Gang Shimano "Deore" | | Gear shift | SHIMANO "Deore" SL-T6000 | | Chain | KMC "X10E" |
|
|---|
| Lights | | Front light | CONTEC "Luna 120 E+" 120 Lux | | Rear light | CONTEC TL-328 E-Stop, mit Stoplicht |
|
|---|
| Extras | | Mudguards | CURANA "Apollo", 65mm, schwarz matt, Spoiler | | Rack | MIK-ALU-GEPÄCKTRÄGER "TA7652A" MIK-System | | Chainguard | HESLING "VELO", Steps, schwarz matt | | Locks | AXA "Solid Plus" | | Kick stands | URSUS "King2", für Victoria Hinterbau, 40 mm, verstellbar | | Pedals | VP "531 E", Alu, Platform Pedal black, Pins silver | | maximum weight allowed | 140 kg |
|
|---|
