| Cadre | | Cadre | Semi-Integrated-Steps-Cadre Aluminium 6061 | | Forme de cadre | Ouvert | | Cadre hauteur | 45 cm | 50 cm | 55 cm | | Forme de cadre/hauteur | Ouvert/45 cm | Ouvert/50 cm | Ouvert/55 cm | | Fourche | SUNTOUR SF19-NEX E25 NLO, einstellbar, Lockout, 63mm Travel, Tapered, DISC | | Couleurs | pine black matt /brown | | Poids max | 140 kg |
|
|---|
| Système moteur | | Type de moteur | Central | | Moteur | SHIMANO Central E6100, 250 W Nenn-Dauerleistung | | Energy content | SHIMANO Lithium-Ion, 36 V, 14 Ah, 504 Wh | | Batterie | 504 Wh | | Ecran | SHIMANO SC-E6100 LCD, Bluetooth, Remote Control, Walk assist | | Sensor | Tretkraftmessung im Moteur + Geschwindigkeitssensor | | Support up to | 25 km/h |
|
|---|
| Poste de pilotage | | Guidon | ERGOTEC Lady Town, 620 mm, Ø31,8 mm, schwarz | | Stem | ERGOTEC Barracuda, Ø31,8 mm, 20 °, schwarz | | Handlebar grips | HERRMANS LineTec | | Saddle | SELLE ROYAL ESSENZA Italy, Relaxed | | Seat Post | ERGOTEC Patent SP10, gefedert, Ø 27,2 mm, Alu |
|
|---|
| Freins | | Freins | SHIMANO BR-MT200 | | Freins lever | SHIMANO BL-MT201 |
|
|---|
| Roues | | Front-wheel hub | SHIMANO HB-M4050, 36 L., QR, Disc, Center Lock | | Rear-wheel hub | SHIMANO Nexus 8 Gg. RT | | Wheel rims | Hohlkammer X-6 DISC, Alu | | Tyres | SCHWALBE Marathon GT Tour, 47-622, Reflex | | Tire size | 28 Zoll/inch | | Spokes | 2,0 mm, Niro, black |
|
|---|
| Vitesses | | producer Leviers vitesses | SHIMANO | | Vitesses | Nabenschaltung | | Vitesses | 8 | | Leviers vitesses | 8-Gang SHIMANO Nexus DI2 RBN | | Gear shift | SHIMANO KS-WE6010R | | Chaine ou courroie | KMC E1 EPT | | Sprocket | SHIMANO, 21 Z. |
|
|---|
| Eclairages | | Eclairage avant | CONTEC Luna 80 E+ 80 Lux | | Eclairage arrière | CONTEC TL-328 E-Stop, mit Stoplicht |
|
|---|
| Extras | | Rack | MIK-ALU-GEPÄCKTRÄGER TA7653A MIK-System | | Chainguard | HESLING Move, Steps, schwarz matt | | Pedals | UNION SP-828, Alu, Antislip | | Locks | AXA Solid Plus | | Mudguards | CURANA Apollo, 55mm, schwarz matt, Spoiler | | Kick stand | URSUS King2, für Victoria Hinterbau, 40 mm, verstellbar |
|
|---|
