| Cadre | | Cadre | Bosch-Intube-SUV-Cadre, Aluminium 6061 | | Forme de cadre | Haut | Ouvert | | Cadre hauteur | 46 cm | 48 cm | 51 cm | 53 cm | 56 cm | 58 cm | | Forme de cadre/hauteur | Haut/48 cm | Haut/53 cm | Haut/58 cm | Ouvert/46 cm | Ouvert/51 cm | Ouvert/56 cm | | Fourche | SUNTOUR SF21-MOBIE34 -D AIR 2CR DS, einstellbar, Lockout, 100mm,Disc, Tapered, QR15 | | Couleurs | olive black / black | | Poids max | 140 kg |
|
|---|
| Système moteur | | Système moteur | BOSCH | | Type de moteur | Central | | Moteur | BOSCH Central Gen.4 Performance CX, 36 V, 250 W | | Energy content | BOSCH Lithium-Ion, 36 V, 16,66 Ah, 625 Wh | | Batterie | 625 Wh | | Ecran | BOSCH, SmartHub 4 modes |
|
|---|
| Poste de pilotage | | Guidon | ERGOTEC Low Riser Bar, 720 mm, Ø 31,8 mm, schwarz | | Stem | ERGOTEC Barracuda Eco, Ø31,8 mm, 20 °, schwarz | | Handlebar grips | CONTEC Tour Wing | | Saddle | SELLE ROYAL ESSENZA Italy, Moderate Female | SELLE ROYAL ESSENZA Italy, Moderate Male | | Seat Post | LIMOTEC DP03-T, Suspesion-Dropper-Post, 40mm travel, 80mm hauteur adjustment |
|
|---|
| Freins | | Freins | SHIMANO BR-MT420/410 | | Freins lever | SHIMANO BR-MT401 |
|
|---|
| Roues | | Front-wheel hub | SHIMANO HB-M8110, QR 15, Disc, Center Lock | | Rear-wheel hub | SHIMANO FH-M8000, 32 L., QR, Disc, Center-Lock | | Wheel rims | MACH1 MAXX | | Tyres | SCHWALBE Johnny Watts, 60-584, Reflex | | Tire size | 27.5 Zoll/inch | | Spokes | 2,0 mm, Niro, black |
|
|---|
| Vitesses | | producer Leviers vitesses | SHIMANO | | Vitesses | Kettenschaltung | | Vitesses | 12 | | Leviers vitesses | 1×12-Gang SHIMANO Deore XT | | Gear shift | SHIMANO Deore XT SL-M8100 | | Dérailleur | SHIMANO XT RD-M8100-SGS, 12-fach | | Chaine ou courroie | KMC X12E | | Sprocket | SUNRACE CSMZ8 11-51 Z. black |
|
|---|
| Eclairages | | Eclairage avant | CONTEC Dlux 120 E+ 120 Lux | | Eclairage arrière | CONTEC TL-335 E-Stop, mit Stoplicht |
|
|---|
| Extras | | Rack | MIK-ALU-GEPÄCKTRÄGER TA7652A MIK-System | | Chainguard | CURANA Chainguard | | Pedals | UNION SP-828, Alu, Antislip | | Locks | CONTEC Powerloc XL AZ | | Mudguards | CURANA Apollo, 65mm, schwarz matt, Spoiler | | Kick stand | URSUS King2, für Victoria Hinterbau, 40 mm, verstellbar |
|
|---|
